2-25 IM WX11-01E
Creat
ng Mon
tor Screens w
th
AddObserver Bu
lder
1
2
3
4
Index
Edtng from the Propertes Dalog Box
1. Click the Edt icon in the OBJECT group of the EDIT page of the operation panel,
or click the Edt button in the object bar.
2. Select the arc you wish to edit in the editing area.
3. Choose Edt > Propertes or right-click and select Properties.
The arc properties dialog box is displayed.
Click here to apply the fill color.
4. Move the cursor to the desired item and click to enter a new value.
5. Click OK.
2.10 Creatng Arcs
