2.7
Creatng Lnes
You can create a line of any length and direction. You can also specify the line’s width,
color, and whether arrowheads are attached to the ends.
Procedure
Creatng a New Lne
1.
Click the Lne icon on the EDIT page of the operation panel, or click the Lne
button in the object bar.
2.
Choose Gadget > Lne Wdth, then select from 0 dots through 5 dots.
3.
Choose Gadget > Arrow, then choose None, Start, End, or Both. You can also
click the No Arrow, Start Pont Arrow, End Pont Arrow, or Both Ponts Arrow
buttons on the attribute bar.
4.
Choose Gadget > Lne Color.
The color settings dialog box is displayed. For details on the color settings dialog
box, see “Choosing a Color from the Color Settings Dialog Box” in section 2.30.
5.
Move the mouse to a location in the editing area where you want to start the line.
6.
Drag the mouse to the end point of the line.
