Yokogawa DAQWORX - Manual (Page 54)

2-43 IM WX11-01E
Creat
ng Mon
tor Screens w
th
AddObserver Bu
lder
1
2
3
4
Index
5. Drag the picture to the frame created in step 3.
(1) Drag the picture you wish to place.
(2) Drop the picture on the picture frame.
The selected picture fills the picture frame.
Note
You can still drag a picture onto the editing area even if you do not first create a frame for it. In
this case, the picture is sized according to the original size of the BMP file.
2.17 Creatng Pctures
