Page 53

2-42

IM WX11-01E

2.17 Creatng Pctures

You can place a “picture” (a bit mapped image) in the monitor screen.

Procedure

Placng a Pcture n the Pcture Folder

Place images in BMP format that you want to have available for use into the

AddObserver/Picture directory created during installation of the AddObserver.

Creatng a New Pcture

Click the Pcture icon on the EDIT page of the operation panel, or click the

Pcture button in the object bar.

Move the mouse to a location in the editing area where you want to place the

picture.

Drag the cursor to the location of the opposite corner of the picture.

A picture frame is created using the two corner points specified in steps 2 and 3.

Move the cursor to the picture you want to place in the PICTURE group on the

EDIT page of the operation panel.
