2.14 Creatng Meters
You can create several different kinds of meters (digital, bar, analog, and thermometer)
and assign channels to them. You can also enter settings for such things as the channel,
text size, and units.
Thermometer
Analog Meter
Bar Meter
Digital
Procedure
Creatng a New Meter
1.
Click the Dgtal, Bar Meter, Analog Meter, or Thermometer icon on the EDIT
page of the operation panel. You can also click the corresponding buttons on the
object bar.
2.
Choose Text > Sze, then select from Auto through 96 ponts.
3.
Move the mouse to a location in the editing area where you want to place the
meter.
4.
Drag the cursor to the location of the opposite corner of the meter.
