Page 25

2-14

IM WX11-01E

2.6

Creatng Labels

You can enter a character string of your choice to create a label. You can also select the

size, style, color, and fill for the text.

Procedure

Creatng a New Label

Click the Label icon on the EDIT page of the operation panel, or click the Label

button in the object bar.

Choose Text > Style, then Bold, Italc, or Underlne. You can also click the Bold,

Italc, or Underlne buttons on the attribute bar. You can also select, Bold and

Italic at the same time.

Choose Text > Sze, then select from Auto through 96 ponts.

Choose Text > Algn, then select Left, Center, or Rght. You can also click the

Left, Center, or Rght buttons on the attribute bar.

Choose Text > Color.

The color settings dialog box is displayed. For details on the color settings dialog

box, see “Choosing a Color from the Color Settings Dialog Box” in section 2.30.
