Dsplayng Objects n Tabs
You can switch windows by clicking tabs on AddObserver Panel.
• Creating a Tab Page
1.
Select an object you wish to display in the tab page. You can also select multiple
objects.
2.
Choose Arrangement > Tabpage or click Tabpage button on the arrangement
bar. If multiple objects are selected, the selected objects are placed in a single tab
page.
• Editing an Object Placed in a Tab Page from the Properties Dialog Box
3.
Select an object you placed in the tab page.
4.
Choose Edt > Propertes. The Properties dialog box for the object is displayed.
Position and size displayed on AddObserver
Tab width
Color of the text displayed
on the tab
Tab color
Text displayed on the tab
5.
Move the cursor to the desired item and enter a new value.
6.
Click OK.
• Grouping Tab Pages
3.
You can group multiple pages.
Select the tab pages to be grouped.
4.
Choose Arrangement > Pagecontroller or click Pagecontroller button on the
arrangement bar.
2.30 Edtng Objects
