2-6 IM WX11-01E
2.4 Enterng Host and Channel Settngs
To display monitor screens (panels) using AddObserver Panel, host settings for
connecting to the DAQ32 Plus, DAQEXPLORER, DAQLOGGER, or MXLOGGER
monitor server, GateCONTROL and GateEye must first be entered in AddObserver
Builder.
Procedure
1. Choose Edt > Confguraton.
The Configuration dialog box is displayed.
HOST tab
Add Delete
Enterng Host Settngs
2. Click the HOST tab. The host settings page appears.
3. Click the Host Type box next to No. 0000, and set the host type to Input
Channel, I/O Channel, or V-Channel. When you connect the GateEye, you must
set the V-Channel.
4. Click the Host box. Enter the name of the computer
1
that will host the monitor
server.
1 The name used to identify the computer on the network. You can also enter the IP
address.
5. Click the Port No. box. Enter the port number
2
of the monitor server to which you
will connect.
2 The default value for the monitor server’s port numbers are 50278 for DAQ32 Plus,
50279 for DAQEXPLORER, 50280 for DAQLOGGER, 50284 for MXLOGGER, 50299
for GateCONTROL and 50290 for GateEye. Make sure you have the right port number,
especially if it may have been changed earlier. For instructions on how to check the port
number, consult the user’s manual for the monitor server you are using.
