Yokogawa DAQWORX - Manual (Page 23)

2-12 IM WX11-01E
Enterng V-CHANNEL Detal Settngs
10. Click the V-CHANNEL tab. The V-CHANNEL setting page is displayed.
V-CHANNEL tab
V-CHANNEL tab
11. To manually enter a tag or tag comment, click the Detail box. changes to
, allowing entry of the tag and tag comment.
Note
Please note that after switching to and entering the tag and tag comment, if you switch
back to , the item reverts to the previous setting.
Go to step 15.
Selectng the Alarms That Wll Sound
15. Click the ALARM SOUND tab. The ALARM SOUND setting page appears.
ALARM SOUND tab
Sound an alarm when a red indication alarm occurs
16. Select the alarm that will sound.
17. Click OK to close the Configuration dialog box.
Note
Be aware that if you click Cancel instead of OK, setting changes will not be saved.
2.4 Enterng Host and Channel Settngs
