2.13 Creatng Indcators
You can create an indicator for any channel’s alarm. You can also create channel or
alarm labels.
Procedure
Creatng a New Indcator
1.
Click the Indcator icon on the EDIT page of the operation panel, or click the
Indcator button in the object bar.
2.
Move the mouse to a location in the editing area where you want to place the
indicator.
3.
Drag the cursor to the location of the opposite end of the indicator.
An indicator is created using the two corner points specified in steps 2 and 3.
4.
Move the cursor to the channel alarm you wish to assign to the indicator on the
channel page of the operation panel.
5.
Drag the alarm to the indicator created in step 3.
(1) Drag the channel alarm you wish to assign.
(2) Drop the channel alarm plate on the indicator.
