Note
Settng Shortcut Buttons
The gray setting shortcut buttons are located just under the last channel row on the channel
page. These buttons help you enter settings more quickly.
Copy Host Number
Fill Channel Numbers
Toggle Attribute
Fill Tag Numbers
Fill Tag Comments
Toggle Format Type
Copy Decimal Point
Copy Value
Copy Value
Copy Units
Default Color
• The Copy Host Number Button
Copies the first host number in the selected range to the rest of the channels in the selected
range. Select the range you want to copy from and to, and click the Copy Host Number
button.
• The Fll Channel Numbers Button
Takes the channel number from the first channel in the selected range, and fills each
remaining channel in the range with a channel number one higher than the previous
channel.
Select the range of channels to fill and click the Fll Channel Numbers button. The channel
numbers are filled incrementally starting with the first channel in the selected range.
• The Toggle Attrbute Button
Toggles the icon for all selected channels between ORIG and USER. Select the range
of channels to change and click the Toggle Attrbute button. The icons of all selected
channels change from ORIG to USER or vice versa.
• The Fll Tag Numbers Button
Takes the tag number from the first channel in the selected range, and fills each remaining
channel in the range with a tag number one higher than in the previous channel. Select the
range of channels to fill and click the Fll Tag Numbers button. The tag numbers are filled
incrementally starting with the first channel in the selected range.
• The Fll Tag Comments Button
Takes the tag comment from the first channel in the selected range, and fills each remaining
channel in the range with a tag comment one higher than the previous channel. Select the
range of channels to fill and click the Fll Tag Comments button. The tag comments are
filled incrementally starting with the first channel in the selected range.
• The Toggle Format Type Button
Toggles the icon for all selected channels between F and E. Select the range of channels
to change and click the Toggle Format Type button. The icons of all selected channels
change from F to E or vice versa.
• The Copy Decmal Pont Button
Copies the number of decimal places specified in the first channel in the selected range to
the rest of the channels in the selected range. Select the range you want to copy from and
to, and click the Copy Decmal Pont button. The number of decimal places is copied to the
selected range.
• The Copy Value Buttons
Copies the value from the first channel in the selected range to the rest of the channels
in the selected range. Select the range you want to copy to and from, and click one of the
Copy Value buttons. The value is copied to the selected range.
• The Copy Unts Button
Copies the value from the first channel in the selected range to the rest of the channels in
the selected range. Select the range you want to copy from and to, and click the Copy Unts
button. The units are copied to the entire range.
• The Default Color Button
Loads the default color values for all channels in the selected range. Select the desired
range and click the Default Color button. The default color values for all channels in the
selected range are loaded.
