2.30 Edtng Objects
The following is the procedure for editing any monitor screen object.
Selectng an Object
The following are the two ways to select an object.
• Clckng the Left Mouse Button
Move the mouse over the object you wish to select and click the left mouse button.
To select multiple objects, hold down the shift key while clicking the objects.
• Draggng a Selecton Frame
Move the mouse near the objects you wish to select, then drag a frame around them.
All objects within the frame will be selected. The left-most object within the graph of
selected objects is called the primary selected object.
Procedure
Movng Objects
1. Select the object or objects you wish to move. The selected object or objects are
surrounded by a frame with 8 anchor points.
2. Drag the selected object(s) to move them.
Reszng Objects
1. Select the object(s) you wish to resize.
2. Drag the anchor points of the selected object(s) to resize them.
Deletng Objects
1. Select the object(s) you wish to delete.
2. Press the Delete key, choose Edt > Cut, or click the Cut button on the toolbar.
Cut
