2-68

IM WX11-01E

2.29 Adding Monitor Windows

You can add up to 7 monitor windows. The monitor windows that are added can also be
displayed simultaneously on AddObserver Panel.

Procedure

Adding a Window

Choose

Edit > Add Subwin. A window is added. You can add up to 7 monitor

windows. The windows that are added are automatically assigned tab names
“SubWinX” (where X = 01 to 07).

Create a monitor window according to the aforementioned procedure.

Note

You can select whether to show or hide the sub windows when monitor windows are displayed
on AddObserver Panel. For details, see section 2.32, “Changing Monitor Window Display
Properties.”

Deleting a Window

Display the monitor window you wish to delete.

Choose

Edit > Delete Subwin. The window is deleted. You cannot delete the

main window.
