14-26 IM DR232-01E
14.8 Alarm Module
Style Number: S2
Type, Number of outputs, Contact mode, Terminal type
Contact mode
Transfer contact (NO-C-NC)
Make contact(NO-C)
Terminal type
screw
screw
Number of
output
4
10
Type
DT200-11
DT200-21
Normal operating temperature/humidity
20 to 80%RH for 0 to 40 °C, 10 to 50%RH for 40 to 50°C (no condensation)
Output updating rate
every measurement interval
Contact mode
Make contact : normal open/common contact type
Transfer contact: normal open/common/normal close type
Energize/de-energize
switchable
Hold/non-hold
switchable
Reflash alarm
up to 6 contacts can be specified.
Contact capacity
250V DC/0.1A (with a resistor load)
250V AC/2A (with a resistor load)
30V DC/2A (with a resistor load)
Dielectric strength
Between the output terminal and ground: 2300V AC (50/60Hz) for one minute.
Power consumption
Included in the main unit or the subunit to which the module is to be installed.
External dimensions and weight
Weight (kg)
0.3
0.4
External dimensions(W) × (H) × (D)mm
apporox. 57 Ч137Ч68
apporox. 57 Ч137Ч68
Type
DT200-11
DT200-21
