Setup
MLS User’s Guide 87
Setup Loop Alarms
Press Yes at the Setup Loop Alarms prompt to access menus which
change alarm function parameters for the current loop. The main alarms
menu looks like this:
Below is the alarms menu tree. Notice the default values inside the
boxes.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
SETUP LOOP 04
ALARMS ?
Setup Loop Alarms?
High process
alarm setpoint?
1000 º F
High process
alarm type?
OFF
High process alarm
dig out? NONE
Deviation alarm
value? 5
º F
High deviation
alarm type? OFF
High deviation
alarm dig out?
NONE
Low deviation
alarm type? OFF
Low deviation
alarm dig out?
NONE
Low process
alarm setpoint?
0 º F
Low process
alarm type? OFF
Low process
alarm dig out?
NONE
Alarm deadband?
2 º F
Alarm delay?
0 Seconds
