Installation
MLS User’s Guide 23
Mounting the MLS-PS
Follow these instructions to mount the MLS-PS.
If you use your own power supply for the MLS, please refer to the
power supply manufacturer's instructions for mounting information.
Choose a power supply that supplies a regulated 7-28 Vdc at 1 watt, and
isolated return line.
Mounting Environment
The MLS-PS measures 1.75" x 8" x 5". Leave enough clearance around
the power supply that you can remove it later.
Mounting Steps
The MLS-PS has a bracket at each end of the unit. Each bracket has
three screw holes which will accept #6 or #10 screws. To mount the
MLS-PS, insert screws into the brackets and tighten them.
