Test digital output, Toggle digital output – Watlow MLS User Manual
Page 110
98 MLS User’s Guide
Setup
Toggle Digital Output
Use this menu to manually toggle a digital output On or Off to test it.
(You select the output to test in the previous menu.) On may be Low or
High depending on the digital output polarity you set in the Output
Polarity menu. (All outputs are set to Off when you exit Manual I/O Test
menu.)
Selectable values: On or Off.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
DIGITAL OUTPUT
NUMBER 17? OFF
