Setup
MLS User’s Guide 93
High Deviation Alarm Output Number
Use this menu to assign a digital output which activates when the loop is
in high deviation alarm. The digital output only activates if you have set
the high deviation alarm type to Alarm or Control.
NOTE
All digital outputs are "OR'ed" together (combined).
Therefore you can assign more than one alarm to the
same output number, and that output will be On if any
of those alarms is On.
Selectable range: Any output number between 1 and 34, as long as it
isn’t used for control or the SDAC clock. You may also select NONE.
Low Deviation Alarm Type
Use this menu to turn Off the low deviation alarm or set it to Alarm or
Control mode.
Selectable values: Alarm, Control, Off.
Low Deviation Alarm Output Number
Use this menu to assign a digital output that activates when the loop is in
low deviation alarm.
Selectable values: Any output number between 1 and 34, as long as it
isn’t used for control or the SDAC clock. You may also select NONE.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
01 HI DEV ALARM DIG
OUT ? NONE
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
12 LO DEVIATION
ALARM TYPE ? OFF
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
12 LO DEV ALARM
DIG OUT? NONE
