Setup
MLS User’s Guide 83
Heat/Cool Cycle Time
Use this menu to set the Cycle Time for Time Proportioning outputs.
Selectable range: 1-255 seconds.
NOTE
The Cycle Time menu will only be present if the out-
put type for the current loop is Time Proportioning.
SDAC Menus
If you attach the optional SDAC to an output, you must configure that
output for the SDAC using the following series of menus. The MLS will
also assign digital output #34 as a clock line for the SDAC. You won't be
able to assign another function to output #34 while any loop's output is
set to SDAC.
SDAC Mode
Use this menu to toggle the SDAC between current and voltage output.
The SDAC menus only appear if the output type for the loop is set to
SDAC.
Selectable values: Current and Voltage.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
03 HEAT OUTPUT
CYCLE TIME ? 10S
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
01 SDAC MODE ?
VOLTAGE
