Setup
MLS User’s Guide 63
Job Select Inputs
Use the Remote Job Control feature to run up to 8 jobs remotely. The
Job Select Inputs menu is the third menu under Setup Global
Parameters. It lets you set the number of job select inputs. The controller
uses these inputs as a binary code that specifies the job number to run.
The number of inputs you choose in this menu controls the number of
jobs you can select remotely. The menu looks like this:
Selectable values: 1, 2, 3 , or NONE.
Below is the truth table that tells you which input states select which
jobs.
You can choose 1, 2, or 3 inputs, or None. These choices have the
following effect:
Digital
Input 3
Digital Input
2
Digital Input
1
Job #
F F F 1
F F T 2
F T F 3
F T T 4
T F F 5
T F T 6
T T F 7
T T T 8
Setting Enables
1 input Jobs 1-2
2 inputs Jobs 1-4
3 inputs Jobs 1-8
None (no inputs) Remote Select disabled
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
JOB CONTROL DIG
INPUTS? NONE
