Mounting the mls-pm, Mounting environment, Mounting steps – Watlow MLS User Manual
Page 4: Mounting the mls-ps (from page 23)
II MLS User’s Guide (11570-00 rev. 3.6)
Addendum for MLS User’s Guide (3.6)
Mounting the MLS-PS (from page 23)
Follow these instructions to mount the MLS-PS.
If you use your own power supply for the MLS, please refer to the
power supply manufacturer's instructions for mounting information.
Choose a power supply that supplies a regulated 10 to 28 Vdc at 1 watt,
and isolated return line.
Mounting Environment
The MLS-PS measures 1.40" x 8" x 3.9". Leave enough clearance
around the power supply that you can remove it later.
Mounting Steps
The MLS-PS has a mounting bracket. The bracket has two screw holes
which will accept #6 or #10 screws. To mount the MLS-PS, attach the
power supply to your panel with the two screws and the power supply
mounting bracket.
