74 MLS User’s Guide
Setup
Display Format
Use this menu to select a display format for a linear input. Choose a
format appropriate for your input range and accuracy.
Selectable values: The MLS has several available display formats, as
shown below. this table shows also the high and low PV values. .
High Process Value
Use this menu to enter a high process value. The high process value and
the high reading value together define one of the points on the linear
scaling function's conversion line.
Selectable values: See table above.
Display Formats High PV Default Low PV Default
-9999 to +30000 10000 0
-999 to +3000 1000 0
-99 to +300 100 0
-9 to +30 10 0
-.9999 to +3.0000 1.0000 .0000
-9.999 to +30.000 10.000 .000
-99.99 to +300.00 100.00 .00
-999.9 to +3000.0 1000.0 .0
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
05 DISP FORMAT
-9999 TO 30000
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
01 INPUT SCALING
HI PV? 10000
º F
