62 MLS User’s Guide
Setup
Save to Job
Use this menu to save the job information for every loop to one of eight
jobs in the MLS’ battery-backed RAM.
Selectable Range: 1-8.
If you have enabled the remote job control function, you will not be able
to save a job; when you try to do it, you will see this message:
Load from Job
Use this menu to load any one of eight saved jobs from the controller’s
front panel.
Selectable values: The last job number or job 1.
The following parameters are loaded as part of a job:
1. PID constants, filter settings, setpoints, and spread values.
2. Loop control status (Automatic or Manual), and output values (If the
loop is in Manual control).
3. Alarm functions (Off, Alarm, Control), setpoints, high/low process
setpoints, high/low deviation setpoints and deadband settings, and
loop alarm delay.
If you have enabled the remote job control function, this menu is
disabled .
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
SAVE SETUP
TO JOB? 1
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
CANNOT SAVE JOB
REMOTE SELECT
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
LOAD SETUP
FROM JOB? 1
