Addendum for MLS User’s Guide (3.6)
MLS User’s Guide (11570-00 rev. 3.6) I
Addendum for MLS User’s
Guide (3.6)
The following are changes to revision 3.6 of the MLS User’s Guide. The
changes pertain to a new power supply that is being used with the MLS.
All changes are listed below by page number. Shaded portions refer to
the actual changed text.
These changes will be incorporated in the next manual revision.
System Power Requirements (from page 10)
Dimensions and Weight (from page 10)
MLS-PM supply input 10-28 Vdc at <1 amp
MLS-AIM supply input 4.75 to 5.25 Vdc at <0.5 amp, supplied by MLS-
PM
MLS-PS system power supply Input: 120/240 Vac at 0.75 amp
Output: 15 Vdc at 1.2 amp, 5 Vdc at 4 amp
MLS-PM 1.75 lbs., 1.89" x 3.78" x 6.75" (0.8 kg, 4.75 cm x 10 cm x 17
cm.)
MLS-AIM-TB
& AIM cards
1.50 lbs., 5.0" x 6.50" x 5.50" (0.7 kg, 12.5 cm x 16.25 cm x
13.75 cm.)
MLS-PS 1.2 lbs., 1.40" x 8.0" x 3.9" (0.6 kg, 3.56 cm x 20.32 cm x 9.91
cm.)
RTB .5 lbs, 5.0’’ x 3.0’’ x 2.25’’ (.227 kg, 12.7 cm x 7.6 cm x 5.7 cm.)
