Recommended wire gauges – Watlow MLS User Manual
Page 57
Installation
MLS User’s Guide 45
Recommended Wire Gauges
This table shows maximum distances and wire gauges for
communications wiring:
You may wish to use a shield, depending on your noise environment and
grounding problems. These cables are shielded.
Distance
Wire Gauge
Recommended Cable
4000 ft.
24 AWG
Belden #9729
Belden #9842
6000 ft.
22 AWG
Belden #9184
