WAFER-LX User Manual
BIOS Menu 11: Power Management Setup
ACPI Function [Enabled]
The ACPI Function option allows you to enable or disable the ACPI function.
Disabled The ACPI function is enabled
Enabled (D EFAULT ) The ACPI function is disabled
ACPI Suspend Type [S1(POS)]
The ACPI Suspend Type option allows you to select the suspend state your computer will go into
during the power conservation mode.
S1(POS) (D EFAULT ) System appears off. The CPU is stopped; RAM is
refreshed; the system is running in a low power mode.
Power Management [User Define]
The Power Management option allows you to manually define the Suspend Mode and the HDD
Power Down options. BIOS has preset minimum and maximum values for the Suspend Mode
and the HDD Power Down options.
User Define (D EFAULT ) The user defines the Suspend Mode time and the
HDD Power Down time.
Min. Saving BIOS automatically sets the Suspend Mode time
and the HDD Power Down time for minimum
power saving.
Max. Saving BIOS automatically sets the Suspend Mode time
and the HDD Power Down time for maximum
power saving.
The minimum and maximum power settings are shown below:
Suspend Mode HDD Power Down
Min. Saving 1 hour 15 minutes
Max. Saving 1 minute 1 minute
