WAFER-LX

Table 2-2 Interface

Connectors

Label

Function

CN1

4P power connector

CN2

3-pin PS-ON/ATX feature connector/selector

WARNING!

A 20-pin-to-4P+3-pin adapter cable comes as an option for configurations

using ATX power supply. This adapter cable is different from the similar

cables provided with the previous WAFER series models. The “Ground”

pin is removed from the 3-pin header of this cable; and, if a cable of the

previous design is connected to CN2, serious damage to the embedded

board will occur.

CN3

5-pin Inverter control

CN4

3-pin CPU fan connector

CN5

5-pin External LED connector (to chassis LED controller board)

CN6

144-pin SDRAM SO-DIMM socket

CN7

2-pin connector to the external Lithium 3V coin cell battery-

CN8

10-pin audio connector (to the external adapter cable kit which

should provide phone jacks for Line_out, Line_in, and MIC_in

connectivity)

CN9

Not implemented.

CN10

PC/104 connector (104-pin ISA bus)

CN11

3-pin external -VCC power connector. It is a peripheral power

connector, provides a -5V and -12V sources as -VCC voltage that

are supplementary to the PC/104 (CN10) connector.

CN12

2-pin Reset button switch (to the chassis front panel)

CN13

2-pin Power switch button (to the chassis front panel)

CN14

10-pin general purpose I/Os connector

CN15

26-pin parallel port pin header
