WAFER-LX User Manual
Product Overview
1.1 General Information
The WAFER-LX is a highly-integrated embedded computer specifically optimized
for multi-media applications requiring minimum installation space. The WAFER-LX
is particularly suitable for low power and fan-less applications. The WAFER-LEX
supports a full range of functionality for an AT/ATX-compatible industrial computer in
a space-saving 3.5” profile. The WAFER-LEX is equipped with a low-power
consumption and high performance AMD Geode LX800 processor on board. It
also contains an SDRAM SODIMM socket that supports up to 1GB memory in size.
Figure 1-1 WAFER-LX Board Layout
1-2
