IEI Integration WAFER-LX v1.0 - Manual (Page 71)

WAFER-LX User Manual
1. Date [mm:dd:yy]: Allows you to set the system date.
2. Time [Day hh/mm/ss]: Allows you to set the system time.
IDE Master and IDE Slave
When entering setup, BIOS auto detects the presence of IDE devices. This displays the status of
the auto detected IDE devices. The following IDE devices will be detected and are shown in the
Standard CMOS Features menu:
1. Primary IDE Master
2. Primary IDE Slave
3. Secondary IDE Master
4. Secondary IDE Slave
The IDE Configuration menu (BIOS Menu 3) allows you to set or change the configurations for the
IDE devices installed in the system. If an IDE device is detected, and one of the above listed four
BIOS configuration options are selected, the IDE configuration options shown in Section 1.1.6
appear.
Drive A [1.44M, 3.5in]
The Drive A configuration option determines the type of floppy drive installed in the system. The
floppy drive configuration options are listed below.
1.
None
2.
1.44M, 3.5 in (D EFAULT )
Halt On
The Halt On category allows users to determine whether the computer will stop if an error is
detected during power up.
All Errors (D EFAULT ) Whenever BIOS detects a non-fatal error the
system will be stopped and you will be
prompted.
No Errors The system boot will not be stopped for any
errors that may be detected
All, But Keyboard The system boot will not stop for a keyboard
error; it will stop for all other errors.
All, But Diskette The system boot will not stop for a disk error;
it will stop for all other errors.
4-6 IEI ® Technology, Corp. 4-6
