WAFER-LX User Manual
Introduction
A licensed copy of Phoenix Award BIOS is preprogrammed into the ROM BIOS. The BIOS setup
program allows users to modify the basic system configuration. This chapter describes how to
access the BIOS setup program and the configuration options you may change.
1.1.1 Starting Setup
The Phoenix Award BIOS is activated when you turn on the computer. The setup program can be
activated in one of two ways.
1. Press the D ELETE key as soon as the system is turned on or
2. Press the D ELETE key when the “Press Del to enter SETUP” message
appears on the screen.
If the message disappears before you respond, you must restart your computer and try again.
1.1.2 Using Setup
Use the arrow keys to highlight items, press E NTER to select, use the PageUp and PageDown keys
to change entries, press F1 for help and press E SC to quit. Navigation keys are shown in.
Key Function
Up arrow Move to the item above
Down arrow Move to the item below
Left arrow Move to the item on the left hand side
Right arrow Move to the item on the right hand side
+/Page up Increase the numeric value or make changes
-/Page down Decrease the numeric value or make changes
Esc Main Menu – Quit and not save changes into CMOS
Status Page Setup Menu and Option Page Setup Menu --
Exit current page and return to Main Menu
F1 General help, only for Status Page Setup Menu and Option
Page Setup Menu
F2 Item help
F5 Previous values for the page menu items
F6 Fail-safe defaults for the current page menu items
F7 Optimized defaults for the current page menu items
