WAFER-LX
1.3 Technical Specifications
Table 1-2 Technical Specifications
CPU
Embedded AMD Geode [email protected] processor at 500MHz
frequency
Chipset
Geode CS5536D as Southbridge
Memory
One 64-bit PC 100/133 144-pin SODIMM socket that supports
SDRAM memory up to 512MB
Display Controller
Integrated ProSavage4 w/ 3D/2D/Video controller
Supports AGP 4x performance
Supports single cycle 128-bit 3D architecture
24-bit TTL/single-channel 18-bit DSTN/TFT flat panel interface
Integrated 2-channel 110MHz LVDS interface
Support for all resolutions up to 1024X768 pixels
Hardware Suspend/Standby control
PCI Interface
PCI 2.2 compliant, 32-bit 3.3V PCI interface w/ 5V tolerant
inputs
Up to 5 PCI masters
PCI to system memory data streaming support
10/100Mbps
Realtek8100C
Ethernet
Controller
IEEE 802.3 10/100M Base-T standard auto-sensing interface to
10Mbps or 100Mbps networks through an onboard RJ-45
connector.
BIOS
AMI 256KB Flash memory
Compact Flash
Disk
Runs in true IDE mode that simulates the operation of a physical
IDE hard drive. It can be used with a passive adapter in a Type
II socket in DMA mode.
IDE Interface
Supports one ATA33/66/100 IDE channel with the connectivity
to two hard disk drives
FDD Interface
Supports one optional floppy disk drive, 3.5” (720KB or 1.44MB )
by a 26-pin FPC connector cable.
1-9 1-9
