USB Connection (CN24 and CN19)
The combo USB header (CN24) provides the connectivity of up to two (2) USB (Universal Serial
Bus) ports. The USB interface features complete Plug and Play, and hot attach/detach for up to
127 external devices, compliance with USB specification Rev. 1.1. An adapter 10-pin-to-USB
cable is required for connecting to CN24. The USB interface is accessed through two 5 x 2-pin
connectors, USB01. The adapter cable has one (1) 5x2-pin connector on one end and a
standard USB connector on the other.
Accessories Included in Kit
IEI provides the following cables to facilitate connections to your peripheral devices. For more
information on the locations of the connectors, please refer to Chapter 2. Cables not included in
kit are the user supplied items and should be separately purchased.
Table 3-4 Cables and Accessories Included in Kit
No. Type
1 IDE flat cable 44p/44p (P/N: 32200-000009-RS)
2 SATA cable (P/N: 32000-0628000-RS)
1 SATA power cable (P/N: 32100-086600-RS)
1 PS/2 KB/MS cable (P/N: 32000-000138-RS)
1 Audio adapter cable (P/N: 32000-072100-RS)
1 COM2 serial port cable (RS-232/422/485 compatible; P/N: 32200-000061-RS)
3-12 3-12
