WAFER-LX
AC ’97 interface
Provides 10 Pin Audio header.
16-bit, full-duplex AC'97 Rev. 2.3 compatible six-channel audio
CODEC designed for PC multimedia systems, including host/soft
audio and AMR/CNR-based designs.
Meets performance requirements for audio on
PC99/2001 systems
Meets Microsoft WHQL/WLP 2.0 audio requirements
16-bit Stereo full-duplex CODEC with 48KHz
sampling rate
Compliant with AC'97 Rev 2.3 specifications
Front-Out, Surround-Out, MIC-In and LINE-In Jack Sensing
14.318MHz -> 24.576MHz PLL to eliminate crystal
12.288MHz BITCLK input
Integrated PCBEEP generator to save buzzer
Interrupt capability
Packing List
2xSATA cables (P/N: 32000-062800-RS)
1xAudio adapter cable (P/N: 32000-072100-RS)
1x4P-to-SATA power adapter cable (P/N: 32100-088600-RS)
1xIDE flat cable 44p/40p/40p (P/N: 32200-000061-RS)
1xsecond serial port (COM2) cable (P/N: 32200-000009-RS)
1xKeyboard/ PS2 mouse cable (P/N: 32000-000138-RS)
1xMini jumper pack (P/N: 33100-000079-RS)
1xDriver and Utility CD -
1xQIG (Quick Installation Guide) (P/N: 51000-001109-RS)
System Monitoring
The WAFER-LX is capable of self-monitoring various aspects of its operating status:
Vcore voltage, +3.3V, +5V, and +2.5V
RPM of cooling fans (not implemented with this model)
CPU and board temperatures (by the corresponding embedded sensors)
