WAFER-LX

1.

Master Drive PIO Mode

2.

Slave Drive PIO Mode

3.

IDE Primary Master UDMA

4.

IDE Primary Slave UDMA

5.

IDE DMA transfer access

6.

IDE HDD Block Mode

7.

Onboard FDC Controller

8.

Onboard Serial Port 1

9.

Onboard Serial Port 2

10.

Onboard Serial Port 3

11.

Onboard Parallel Port

12.

Parallel Port Mode

Select the menu you wish to configure.

1.1.9 OnChip IDE Device

The OnChip IDE Device menu (BIOS Menu 10) allows you to change the IDE device

configurations.

4-27

4-27
