WAFER-LX User Manual
Serial Ports
Two RS-232 ports with 16C550 UART (or compatible) with
16-byte FIFO buffer. COM2 can support RS-422/485 through
jumper setting.
Parallel Port
One parallel port supports SPP/EPP/ECP mode
Audio Connector
One 2x5 pin header supports AC’97 2.3 Line-in, Line-out, and
Mic-in signals.
USB Interface
Four (4) USB ports, Two external and two internal via pin header;
USB 1.1 compliant.
Watchdog Timer
Can be Set to 1 to 255 seconds period. Reset or NMI will be
generated when CPU does not periodically trigger the timer.
PC/104 Interface Direct ISA DMA mode operation.
E2Key
A non-volatile 1Kbit EEPROM is provided to retain application
critical read/write data.
Power Supply
+5V: 2.58A typical, CPU w/ 1x128MB PC-100/133 module
+5V: 2.75A typical, 800MHz CPU w/ 1x128MB PC-100/133
module
Hardware Monitor
System voltage detection
CPU temperature detection
IrDA Port
Supports Serial Infrared (SIR) and Amplitude Shift Keyed IR
(ASKIR) interface
Operating
Temperature
0 ° to 60°C
Form Factors 5.75”(L) x 4”(W) x 1”(H)
1-10
1-10
