WAFER-LX User Manual
Audio Interface
Audio Connector
AC’97 Audio signals are interfaced through a 10-pin flat-cable connector. These signals include
Microphone line-in, line-in stereo, and line-out stereo. An audio 10-pin-to-phone-jack adapter kit
is required.
COM Port Connectors [COM1(CN22), COM2/COM3(CN16)]
The WAFER-LX provides two serial ports (COM1: RS-232; COM2: RS-232/422/485) interfaced
through one DB-9 connector (COM1) and one 14-pin male header. These serial ports facilitate
the connection to serial devices or a communication network, e.g., terminal console.
LCD Panel Connection (CN26, CN28, and CN29)
The PCI SVGA interface on the WAFER-LX connects conventional CRT displays and flat panel
displays including passive LCD and active LCD displays. There are three (3) connectors
onboard for the connection to the three (3) display types:
1. CRT VGA monitors
2. TFT flat panel displays
3. LVDS type LCD panels
One CRT display connector (CN26) is provided as a 15-pin, female D-SUB to connect
conventional CRT displays. Pin assignments can be found in Chapter 2 Functional
Description.
Flat Panel Display Connector (CN28):
CN28 is a 40-pin connector, Hirose DF13A-40DP-1.25V, which can support a 24-bit LCD panel.
A bias control signal, ENVEE, active high on CN28, controls the LCD bias voltage. The LCD bias
voltage shall not be applied until the +5V or +3.3V logical supply and panel video signals become
stable. When powered on, the control signal remains low until receiving the flat panel signals.
CN28 connects up to 24-bit TFT LCD.
