WAFER-LX
Important Features
Major functionalities provided by the WAFER-LX are listed below:
Table 2-1 Important Features
RoHS compliance.
AMD long term support product; embedded AMD processor.
PC/104 PCI-to-ISA extension slot for stack-up configurations
CF II socket (CF card behaves as an IDE boot device if no HDD is
applied).
Embedded Graphics Controller with the support for VGA-interface and
LVDS displays (simultaneous operation).
Supports one dual-channel 18-bit (36-bit) TFT, and with up to 1920 x 1440
resolutions
Aluminum alloy heatsink for optimum heat dissipation in fan-less
installations.
Supports dual-channel 18-bit LVDS and/or 24-bit TFT LCD interface
System Memory: one 144-pin SODIMM socket for 64-bit, 400MHz
memory modules ranging from 64MB to 1GB in size.
64KB I/ 64KB D L1 cache and 128KB L2 cache for fast I/O turnarounds
Two serial ports, COM1 for RS-232, COM2/3 for RS-232/422/485
USB compliant with the USB rev. 2.0 standard
System Chipset: AMD Geode LX-800 + Geode CS5536AD Southbridge
Hardware Monitor: built-in to monitor CPU Vcore, VCC, CPU/System fan
speed, and temperature detection functionalities.
Independent DMA audio engines
PXE LAN support with ATX power supply
Realtek ® 8100C: Supports 10/100BaseT Ethernet, IEEE 802.3U
compatible full duplex flow control
Audio: ALC203 AC”97 2.3 CODEC
