WAFER-LX User Manual
BIOS Menu 1: Award BIOS CMOS Setup Utility
NOTE:
The following sections will completely describe the menus listed below and
the configuration options available to users.
The following menu options are seen in BIOS Menu 1.
1. Standard CMOS Features: Changes the basic system configuration.
2. Advanced BIOS Features: Changes the advanced system settings.
3. Advanced Chipset Features: Changes the chipset configuration features
4. Integrated Peripherals: Changes the settings for integrated peripherals
5. Power Management Setup: Allows you to configure power saving options
6. PCIPnP: Changes the advanced PCI/PnP Settings
7. PC Health Status: Menu that monitors essential system parameters
The following user configurable options are also available in the BIOS Main Menu
Load Fail-Safe Defaults
This option allows you to load failsafe default values for each of the parameters on the Setup
menus. F6 key can be used for this operation on any page.
Load Optimized Defaults
This option allows you to load optimal default values for each of the parameters on the Setup
menus. F7 key can be used for this operation on any page.
Set Supervisor Password
By default no Supervisor Password is set. If you wish to install a supervisor password, select this
field and enter the password. After this option has been selected, a red dialogue box with “Enter
Password: ” will appear. You will be asked to confirm your password. Retype the original
password into the “Confirm Password: ” dialogue box and press enter.
Change User Password
By default no User Password is set. If you wish to install a user password, select this field and
enter the password. After this option has been selected, A red dialogue box with “Enter
