KINO-CV-D25501/N26001 SBC
Page 73
ƒ Security – Sets User and Supervisor Passwords.
ƒ Save & Exit – Selects exit options and loads default settings
The following sections completely describe the configuration options found in the menu
items at the top of the BIOS screen and listed above.
5.2 Main
The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
BIOS Information
BIOS Vendor
American Megatrends
Core Version 4.6.5.3 0.16
Compliency UEFI 2.3; PI 1.2
Project Version B229AR10.ROM
Build Date 05/11/2012 17:07:26
System Date
[Tue 05/14/2012]
System Time [14:20:27]
Access Level Administrator
Set the Date. Use Tab to
switch between Date
elements.
----------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 1: Main
Î BIOS Information
The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information
cannot be changed. The items shown in the system overview include:
ƒ BIOS Vendor: Installed BIOS vendor
ƒ Core Version: Current BIOS version
ƒ Project Version: the board version
ƒ Build Date and Time: Date and time the current BIOS version was made
The System Overview field also has two user configurable fields:
