KINO-CV-D25501/N26001 SBC
Page 16
3.1.2 Peripheral Interface Connectors
The table below shows a list of the peripheral interface connectors on the
KINO-CV-D25501/N26001. Detailed descriptions of these connectors can be found below.
Connector Type Label
Battery connector 2-pin wafer CN1
Digital I/O connector 10-pin header DIO1
Fan connectors 3-pin wafer CPU_FAN1,
SYS_FAN1
Front audio connector 10-pin header FRONT-PANEL1
Front panel connector 8-pin header F_PANEL1
Keyboard/mouse connector 6-pin wafer KB_MS1
LVDS connector (1) 20-pin crimp LVDS1
LVDS connector (2) 30-pin crimp LVDS2
LVDS1 backlight connector 5-pin wafer INV1
LVDS2 backlight connector 5-pin wafer INV2
microSD card slot microSD slot CN7
PCI slot PCI slot PCI1
PCIe Mini card slot PCIe Mini card slot M_PCIE1
Power connector (9 V–28 V) 4-pin connector CN3
Power button Push button PWR_SW1
RS-232 serial ports (COM3, COM5, COM6) 10-pin header COM3, COM5,
COM6
RS-422/485 serial port (COM4) 4-pin wafer COM4
SATA connectors SATA connector SATA1, SATA2
SATA power connectors 4-pin wafer SATA_PWR1
SATA_PWR2
SMBus connector 4-pin wafer SMBUS_1
