KINO-CV-D25501/N26001 SBC
Page 8
I/O Interface Connectors
Display Output Ports
(Dual Display Supported)
One Analog CRT (up to 2048 x 1536 @ 75 Hz)
One HDMI (up to 1920 x 1200 @ 60 Hz)
One LVDS 1:
ƒ D2550: 24-bit single-channel LVDS up to 1440 x 900
ƒ N2600 and N2800: 18-bit single-channel LVDS up to 1366 x 768
One LVDS 2: 24-bit dual-channel LVDS by Chrontel CH7511 DP to
LVDS converter
Fan Connectors One 3-pin wafer for CPU fan
One 3-pin wafer for system fan
Keyboard/Mouse One internal 6-pin wafer connector
Serial Ports Five RS-232 COM connectors
One RS-422/485 COM connector
USB Ports Six USB 2.0 (four via pin header, two external ports)
Two external USB 3.0 ports
SMBus One 4-pin wafer connector
Storage
microSD microSD slot (bootable)
SATA Two independent SATA channels with 3.0 Gb/s data transfer rates
(SATA2 and mSATA share SATA signal)
Environmental and Power Specifications
Power Supply Max. power input voltage range: 9 V–28 V
Recommended operating input voltage range: 12 V–24 V
Power Connector 1 x External 4-pin DIN jack
1 x Internal 4-pin (2x2) power connector
Power Consumption 12 V @ 2.8 A (1.86 GHz Intel® Atom™ processor D2550 with one
4 GB 1333 MHz DDR3 SO-DIMM)
12 V @ 2.4 A (1.6 GHz Intel® Atom™ processor N2600 with one 2 GB
1333 MHz DDR3 SO-DIMM)
