KINO-CV-D25501/N26001 SBC
Page 29
Pin Description Pin Description
17 N/C 18 GND
19 N/C 20 N/C
21 GND 22 PCIRST#
23 PCIE_RXN 24 VCC3
25 PCIE_RXP 26 GND
27 GND 28 1.5V
29 GND 30 SMBCLK
31 PCIE_TXN 32 SMBDATA
33 PCIE_TXP 34 GND
35 GND 36 USBD-
37 GND 38 USBD+
39 VCC3 40 GND
41 VCC3 42 N/C
43 GND 44 N/C
45 N/C 46 N/C
47 N/C 48 1.5V
49 N/C 50 GND
51 M-SATA Detect 52 VCC3
Table 3-13: PCIe Mini Card Slot Pinouts
3.2.12 Power Connector (9 V–28 V)
CN Label: CN3
CN Type: 4-pin connector
CN Location: See Figure 3-13
CN Pinouts: See Table 3-14
The power connector is connected to an external power supply and supports 9 V–28 V
power input. Power is provided to the system, from the power supply through this
connector.
