5.3.7 F81866 H/W Monitor
The F8186 H/W Monitor menu (BIOS Menu 10) shows the operating temperature, fan
speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
> Smart Fan Mode Configuration
System Temperature :+42 C
CPU_FAN1 Speed :N/A
SYS_FAN1 Speed :N/A
+VCC_CPU :+1.000 V
+VCC_GFX :+1.648 V
+V1.05S :+1.056 V
VSB5V :+5.016 V
+V3.3S :+3.312 V
VSB3V :+3.360 V
VBAT :+3.216 V
Smart Fan Mode Select
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 10: Hardware Health Configuration
Î PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
ƒ System Temperatures
ƒ Fan Speeds:
o CPU Fan Speed
o System Fan Speed
ƒ Voltages:
o +VCC_CPU
o +VCC_GFX
o +V1.05S
o VSB5V
o +V3.3S
