KINO-CV-D25501/N26001 SBC
Page 57
Figure 4-8: PCIe Mini/mSATA Mode Selection Jumper Location
4.6 Chassis Installation
4.6.1 Airflow
WARNING:
Airflow is critical for keeping components within recommended
operating temperatures. The chassis should have fans and vents as
necessary to keep things cool.
The KINO-CV-D25501/N26001 must be installed in a chassis with ventilation holes on the
sides allowing airflow to travel through the heat sink surface. In a system with an individual
power supply unit, the cooling fan of a power supply can also help generate airflow
through the board surface.
4.6.2 Motherboard Installation
To install the KINO-CV-D25501/N26001 motherboard into the chassis please refer to the
reference material that came with the chassis.
