KINO-CV-D25501/N26001 SBC
Page 17
Connector Type Label
SO-DIMM connector SO-DIMM connector DIMM1
SPDIF connector 5-pin header SPDIF1
SPI Flash 6-pin wafer JSPI1
USB 2.0 connectors 8-pin header USB2, USB3
Table 3-1: Peripheral Interface Connectors
3.1.3 External Interface Panel Connectors
The table below lists the rear panel connectors on the KINO-CV-D25501/N26001.
Detailed descriptions of these connectors can be found in a later section.
Connector Type Label
Audio jacks Audio jack AUDIO_CV1
Ethernet and USB 2.0 ports RJ-45, USB LAN2_USB2
Ethernet and USB 3.0 ports RJ-45, USB LAN1_USB1
HDMI connector HDMI HDMI1
Power jack 4-pin DIN PWR1
Serial port connectors (COM1, COM2) Male D-sub 9 COM1
VGA connector Female D-sub 15 CRT1
Table 3-2: Rear Panel Connectors
3.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. This section has complete descriptions of
all the internal, peripheral connectors on the KINO-CV-D25501/N26001.
