KINO-CV-D25501/N26001 SBC
Page 7
1.7 Technical Specifications
KINO-CV-D25501/N26001 technical specifications are listed in Table 1-1.
Specification KINO-CV-D25501/N26001
Form Factor Mini-ITX
On-board CPU 1.86 GHz Intel® Atom™ D2550 dual-core CPU
1.60 GHz Intel® Atom™ N2600 dual-core CPU
1.86 GHz Intel® Atom™ N2800 dual-core CPU (optional)
System Chipset Intel® NM10
Memory D2550 and N2800: One 204-pin 1066 MHz DDR3/DDR3L (1.35V)
SDRAM SO-DIMM (system max. 4.0 GB)
N2600: One 204-pin 800 MHz DDR3/DDR3L (1.35V) SDRAM
SO-DIMM (system max. 2.0 GB)
Graphics Engine D2550 and N2800: Intel® GMA3650 with 640 MHz graphic core speed
N2600: Intel® GMA3600 with 400 MHz graphic core speed
BIOS UEFI BIOS
Digital I/O 8-bit, 4-bit input/4-bit output
Ethernet Controllers Two Realtek RTL8111E PCIe GbE controllers
(LAN1 supports ASF 2.0)
Audio Realtek ALC662 HD Audio codec
Super I/O Controller Fintek F81866
Watchdog Timer Software programmable supports 1 sec–255 sec system reset
Expansions 1 x PCIe Mini slot supports mSATA SSD ((SATA2 and mSATA share
SATA signal))
1 x PCI slot
