KINO-CV-D25501/N26001 SBC

Page 94

5.4.1.1 Intel IGD Configuration

Use the Intel IGD Configuration menu to configure the video device connected to the

system.

Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.

Chipset

Intel IGD Configuration

IGFX - Boot Type

[VBIOS Default]

LVDS1 Panel Type

[800x600 LVDS]

Backlight Control

[Inverted]

Fixed Graphics Memory Size

[128MB]


Select the Video Device
which will be activated
during POST.
This has no effect if
external graphics
present.


---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter

Select

F1 General

Help

F2 Previous

Values

F3 Optimized
Defaults
F4 Save

ESC Exit

Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.

BIOS Menu 16: Intel IGD SWSCI OpRegion

Î IGFX - Boot Type [VBIOS Default]

Use the IGFX - Boot Type option to select the display device used by the system when it

boots. Configuration options are listed below.

ƒ VBIOS

Default

D

EFAULT

ƒ CRT

ƒ CRT + HDMI

ƒ LVDS1

ƒ LVDS2

Î LVDS1 Panel Type [800x600 LVDS]

Use the LVDS1 Panel Type option to select the type of flat panel connected to the system.

Configuration options are listed below.
