SPCIE-5100DX PICMG 1.3 CPU Card

Page 66

bracket. To secure the bracket to the chassis please refer to the installation

instructions that came with the chassis.

Step 0:

4.8 External Peripheral Interface Connection

The following external peripheral devices can be connected to the external peripheral

interface connectors.

RJ-45 Ethernet cable connectors

USB devices

VGA connector

To install these devices, connect the corresponding cable connector from the actual

device to the corresponding SPCIE-5100DX external peripheral interface connector

making sure the pins are properly aligned.

4.8.1 LAN Connection (Single Connector)

There are two external RJ-45 LAN connectors. The RJ-45 connectors enable connection

to an external network. To connect a LAN cable with an RJ-45 connector, please follow

the instructions below.

Step 1:

Locate the RJ-45 connectors. The locations of the USB connectors are shown in

Chapter 4.

Step 2:

Align the connectors. Align the RJ-45 connector on the LAN cable with one of

the RJ-45 connectors on the SPCIE-5100DX. See Figure 4-22.
