SPCIE-5100DX PICMG 1.3 CPU Card

Page 8

1.6 Technical Specifications

SPCIE-5100DX technical specifications are listed below.

Specification

SPCIE-5100DX

Form Factor

PICMG 1.3

Socket

LGA771 (Socket J)

CPU Supported

Intel® dual-core Xeon® 5100 series CPU

Intel® dual-core Xeon® 5200 series CPU

Intel® quad-core Xeon® 5300 series CPU

Intel® quad-core Xeon® 5400 series CPU

Front Side Bus (FSB)

1066 MHz or 1333 MHz

Northbridge Chipset

Intel® 5100 MCH

Southbridge Chipset

Intel® ICH9R

Memory

Four 240-pin 8.0 GB (max.) 667 MHz or 533 MHz

dual-channel DDR2 SDRAM ECC Registered DIMM

supported (system max. 32.0 GB)

Audio

Optional 7.1 channel HD Audio kit with Realtek ALC883

audio codec

LAN

Two Intel® 82574L PCIe GbE controllers

Super I/O Controller

ITE IT8718F

BIOS

AMI SPI BIOS

Watchdog Timer

Software programmable supports 1~255 sec. system reset

Digital I/O

8-bit digital I/O, 4-bit input and 4-bit output

Expansion

PCI

Four PCI slots

PCIe

PCIe x16 signal to backplane

PCIe x4 signal to backplane
