Adding, Inserting and Deleting Test Cases
Test Scripts are built block-by-block in this fashion
by adding new test cases to the end of the script
using the Reset/Initialize or Test Case buttons at
the bottom of the script.
New test cases can be inserted at any point in the test script
by using the "Insert Above" button
which is located in the
top left of each block . When this button is clicked, the menu
shown on the right appears to allow you to insert either a
Reset/Initialize block or a Receiver test case block. By
default, the new test case is a copy of the existing test case.
Blocks can be deleted from the script by using the "Delete" button , also in the top right
corner of each block.
